PROFILE AIM CINEMA ONE

PROFILE AIM CINEMA ONE

Profile AIM Cinema One

Description

AIM Series in-ceiling speakers were the first to feature an aimable woofer/tweeter module that aims the sound in any direction you choose. No longer are you bound by the design of your room. Just mount the speakers wherever it’s convenient and point them wherever you want sound. Profile grilles are available in AIM8, AIM7 and AIM5 models.

Specifications

Flangeless Appearance
Pivoting 1″ Silk Dome Tweeter
Two 5¼” Injection Molded Graphite Cone Woofers with Phase Plugs
Two 6″ Kevlar® Impregnated Paper Cone Woofers
Front-Mounted Bass Adjustment Switch
Bi-Amping Feature

Other Specifications

General
  • FamilyProfile AIM Cinema
  • Woofer Size5.25 (Inches)
  • Woofer ConstructionTwo 5¼” Injection Molded Graphite Cone Woofers with Phase Plugs . Two 6″ Kevlar® Impregnated Paper Cone Woofers
  • Frequency Response40Hz – 20kHz
  • Impedance8 (Ohms)
  • Sensitivity89 (dB)
  • TimbreTimbre-Matched to All One Series Speakers
  • Dimensions(H x W x D) 30 1/4″ x 9″ x 4″ (768 mm x 229 mm x 102 mm) (with Grille)
  • Hole Cutout Dimensions(H x W) 28 3/4″ x 7 1/2″ (730 mm x 191 mm)
Shipping Info
  • Length33.3 (Inches)
  • Width8.2 (Inches)
  • Height11.6 (Inches)
  • Weight17.15 (Lbs)
  • Unit of MeasureEach
  • Master Pack Qty2
Other Specifications
  • Flangeless Appearance
  • Pivoting 1″ Silk Dome Tweeter
  • Two 5¼” Injection Molded Graphite Cone Woofers with Phase Plugs
  • Two 6″ Kevlar® Impregnated Paper Cone Woofers
  • Front-Mounted Bass Adjustment Switch
  • Bi-Amping Feature

Warranty

Limited Lifetime Warranty
