PROFILE AIM LCR5 3

PROFILE AIM LCR5 THREE

Profile AIM LCR5 Three

Description

AIM Series in-ceiling speakers were the first to feature an aimable woofer/tweeter module that aims the sound in any direction you choose. No longer are you bound by the design of your room. Just mount the speakers wherever it’s convenient and point them wherever you want sound. Profile grilles are available in AIM8, AIM7 and AIM5 models.

Specifications

Flangeless Appearance
Pivoting Woofer Baffle
Two 5 1/4″ Aluminum/Magnesium Cone Woofers with Phase Plugs
Pivoting 1″ Aluminum/Magnesium Dome Tweeter
Front-Mounted Switches Allow for up to ±3dB of Bass and Treble Adjustment

Other Specifications

General
  • FamilyProfile AIM LCR
  • Woofer Size5.25 (Inches)
  • Woofer ConstructionTwo 5 1/4″ Aluminum/Magnesium Cone Woofers with Phase Plugs
  • Frequency Response50Hz – 20kHz
  • Impedance86 (Ohms)
  • Power Handling100 (Watts)
  • Sensitivity90 (dB)
  • TimbreTimbre-Matched to All Three/Four Series Speakers
  • SwitchesFront-Mounted Switches Allow for up to ±3dB of Bass and Treble Adjustment
  • Dimensions(H x W x D) 17 1/8″ x 9″ x 4″ (235 mm x 443 mm x 102 mm) (with Grille)
  • Hole Cutout Dimensions(H x W) 7 1/2″ x 14 1/4″ (190 mm x 362 mm)
Shipping Info
  • Length0 (Inches)
  • Width0 (Inches)
  • Height0 (Inches)
  • Weight0 (Lbs)
  • Unit of MeasureEach
  • Master Pack Qty4
Other Specifications
  • Flangeless Appearance
  • Pivoting Woofer Baffle
  • Two 5 1/4″ Aluminum/Magnesium Cone Woofers with Phase Plugs
  • Pivoting 1″ Aluminum/Magnesium Dome Tweeter
  • Front-Mounted Switches Allow for up to ±3dB of Bass and Treble Adjustment
